FX Luminaire PD LED Wall Light
$165.16 – $263.08
Available on backorder
Description
FX Luminaire PD LED Wall Light, for an Organic Look
The FX Luminaire PD LED Wall Light is to the UN LED Wall Light, as the LM LED Wall Light is to the CP LED Wall Light. With the same organic look as the UN, the PD offers a higher level of illumination for those areas where 10 watts is not quite enough. The LevelX system assures that the face plates of these permanently mounted fixtures will remain perfectly level upon completion of any installation. Use the PD alone or install in conjunction with UN to maintain consistent lighting design style.
Please Allow 12-16 business days for shipping
No returns on lighting products
Additional information
Weight | 2.76 lbs |
---|---|
Finish Options | AB-Antique Bronze, AL-Almond, AT-Antique Tumbled, BS-Brass, BZ-Bronze Metallic, CB-Camo Bronze, DG-Desert Granite, DT-Desert Tan, FB-Flat Black, FW-Flat White, NP-Nickel Plate, SB-Sedona Brown, WG-White Gloss, WI-Weathered Iron |
Zoning & Dimming Option |
Features
PD Included
PD: Includes fixture, 2LED board, filters, choice of faceplate finish, and mounting conduit | ||||||||
---|---|---|---|---|---|---|---|---|
PD |
Included Filter | |||||||
Amber |
Metal Finish Options | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
ABAntique Bronze* |
ATAntique Tumbled* |
NPNickel Plate* |
BSNatural Brass |
* May require longer lead time
Powdercoat Finish Options | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
WGWhite Gloss |
FWFlat White |
ALAlmond |
BZBronze Metallic |
DGDesert Granite |
||||||
WIWeathered Iron |
VFVerde Speckle |
SBSedona Brown |
FBFlat Black |
Composite Finish Options | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
DTDesert Tan |
CBCamo Bronze |
PD ORDERING INFORMATION
FACTORY INSTALLED OPTIONS: Order 1 + 2 (optional) + 3 + 4
Step | Description | Code | |||||
---|---|---|---|---|---|---|---|
1 | FIXTURE CODE | PD | |||||
2 | OPTIONAL ZD | ZD (zoning and dimming capability using ZD Technology™ with the Luxor controller) | |||||
3 | LAMP | 2LED (50,000 avg. life hours) | |||||
4 | FINISH | XX (See finish chart) |
EXAMPLE: PD-ZD-2LED-CB = PD – ZD Option – 2LED Board – Camo Bronze Finish
Specifications
PD Spec Chart
Number of LEDs | 2 | |
---|---|---|
Halogen Lumen Output Equivalent |
10 Watt | |
Useful LED Life (L70) | 50,000 hrs avg | |
Input Voltage | 10 to 15V | |
VA Total (Use this number to size the transformer) |
4.8 | |
Watts Used | 4.0 | |
Lumens per Watt (Efficacy) |
6.9 | |
Max Lumens | 26 | |
CRI (Ra) | 80.1 |
